Proximity readers
3-2-1
Enrolling readers
Via softwareOnce the solution for the system to be designed has been opened, click on the on the System
Layout button on the menu on the left. Then click on the “Add device to BUS” button in the
section on the right.
A window will open where it is possible to select the readers to configure and then add to the
configuration.
In the section on the left the number increases in correspondence with the Readers button.
To remove a reader from the structure, it is necessary to access the programming section by
clicking on the relative key in the menu on the left then, from the list displayed, click on the
Delete button that corresponds to the line of the reader in question.
Via keypad
Type-in Code
(Installer PIN)
, PROGRAMMING Readers, Enablements
In this section it is possible to add/remove readers from the configuration, by means of keys
and .
WIRELESS
READERS
During the enrolling phase the Air2-BS200 wireless transceiver will be integrated into the
Prime system by simulating:
• a reader, with an address programmed via the module itself (ADD), by means of buttons
P1 and P2 on the PCB (for details refer to the Module manual)
• up to 10 expansion boards, at addresses ADD, ADD+1, ... ADD+9, to manage the
terminals and to be configured via the “System Layout” section of the Prime/STUDIO
software.
Via softwareOnce the reading procedure has been completed at the control panel, by clicking on the
Proximity readers button on the menu on the left, a list of configured readers will be
provided in the section on the right. The reader simulated by the Air2-BS200 transceiver is
the one with the “ADD” address configured by the module itself.
Via keypad
Type-in Code
(Installer PIN),
PROGRAMMING Readers, ChoosePeripheral
In the list of configured readers, the reader simulated by an Air2-BS200 has a“W” at the end
of its description.
3-2-2
Programming readers
The programming of readers as Prime system peripherals can be done either via software or
from a keypad.
Via softwareClick on the Proximity readers button on the menu on the left to access two programming
sections on the right:
• Configured readers, with the list of all the configured readers. Selecting one of the
options will allow you to configure the parameters of the single reader by clicking on the
button.
• Reader parameters, section with parameters common to all the readers.
Via keypad
Type in Code
(Installer)
, PROGRAMMING Readers, Enablements, ChoosePeripheral
In this section it is possible to program the different parameters of each reader, after having
selected it.
3-2-3
Reader parameters
Table 3-6: Parameters common to all readers
Parameter Software section Installer menu section
Reader Buzzers
OFF
No reader buzzers will emit audible signals when the
entry time, exit time, output time or pre-arm time is
running.
Reader
parameters
Parameters, ReaderBuzz-
ersOFF
Programming the
proximity reader
address
Section for the programming of the proximity reader
addresses.
Readers, Prog. address
Address LED codes
Section for the visualization of how the addresses will
be reproduced on the LEDs.
Not available
