32 Programming the control panel
Anti-intrusion control panels
The basic IP connection parameters can also be programmed by logging in as a user:
Via keypad
Type in Code
(User)
, Settings, IP Par.and Wi-Fi
4-3-1
Connecting to a Wi-Fi network
The connection of the control panel to a Wi-Fi network is possible through the user menu, but
also through Prime/STUDIO software, via a dedicated section.
Via keypad Type in Code (User), Settings, IP Par.and Wi-Fi, Wi-Fi Networks
By pressing the OK button the control panel will start scanning for available Wi-Fi networks,
those found will be listed in order in accordance with their signal strength.
At this point it is possible to select a network and make the connection using the OK button,
entering the required password if necessary.
Note
The connection password can have up to 32 characters.
Connection to a Wi-Fi network is only possible when the network SSID is not hidden.
After modifying these parameters, and in general, on exiting the “Settings” menu option, the
control panel may restart completely.
Via software The software provides a guided procedure obtained by clicking on the Configure Wi-Fi
button.
Note
The procedure is available only when the connection between the PC in use and the control panel is
made via USB.
4-4
“Cloud mode” preset
In order to make it easier for the installer to program a Prime panel registered with the Inim
Cloud service, the software has an option that, if enabled, provides a preset of some of the
control panel parameters that would otherwise have to be programmed individually.
If activated, the software will perform the following default programming: A preset of events
of various types will be applied and must be communicated to the Cloud when they occur.
Enable Modbus
If enabled, the Modbus/IP service on the LAN board
will be activated; in this case it is necessary to
indicate:
• Port
• Access Codes
Connection
parameters,
Modbus
Not available Not available
This section allows you to program the parameters of the IP connection
test.
IP connection
parameters, IP
connection test
parameters
Not available Not available
IP address
Port
Pv4 Address and port connection attempts are
directed to.
Not available Not available
Interval
Time, expressed in seconds, between connection
tests. If “0” is set, the connection test will be
disabled.
Not available Not available
Number of
attempts
Number of connection attempts for each test. Not available Not available
Table 4-4: IP connection
Table 4-5: Preset events for the Cloud
Event
Communication to Cloud in case
of
Event
Communication to Cloud in case
of
Activation Reset Activation Reset
Zone alarm Yes Yes Reader Tamper Yes Yes
Terminal tamper Yes Yes Sounder/flasher tamper Yes Yes
Zone bypass Yes Yes Nexus tamper Yes Yes
Effective arming mode on parti-
tion
Yes No Video detector tamper Yes Yes
Partition armed in Away mode Yes No Expansion Loss Yes Yes
Partition disarmed Yes No Keypad Loss Yes Yes
Overtime request Yes No Reader Loss Yes Yes
Partition failed to arm Yes No Sounder/flasher loss Yes Yes
