Programming manual
Programming peripherals 21
3-5
Programming the Nexus
The programming phase of the Nexus board allows the installer to program the actions the
control panel will perform after receiving a user command over the GSM network, both via
SMS text and phone call. Each command comprises a group of fully-programmable
parameters.
Each time a user requests an operation, via a correctly formatted SMS text command or voice
call to the phone number of the SIM card inserted in the Nexus, the control panel will activate
the shortcut, force the activation of an event and signal confirmation (feedback) of the
command execution.
Via softwareThe following parameters can be programmed solely via the PrimeSTUDIO software. Click on
the Nexus button on the menu on the left, then go to the section on the right to configure the
parameters.
Note
INIM does not guarantee the total availability of all the GSM/GPRS functions described in this manual,
due to the various combinations of GSM/GPRS service providers, SIM types and phone models that may
be in use.
3-5-1
SMS Commands
In the “Programming - SMS Commands” section it is possible to program up to 30 SMS-
activated commands.
To program each command, double click on the corresponding line to open a window for the
configuration of the respective parameters.
Activate STATUS LED
Enable/Disable activation of the STATUS LED
Activate PRG LED
Enable/Disable activation of PRG LED
Activate TAMPER out-
put
Enable/Disable activation of TAMPER output
Activate FAULT output
Enable/Disable activation of FAULT output
Test
Buttons to start and stop a test on the pattern selected via the audio output of
the PC in use and the image of the sounder/flasher on the left of the buttons.
Stop
Test sounder/flasher
pattern
Test
Buttons to start and stop a test on the selected
pattern on the sounder/flasher selected from the list
provided.
This test requires an active connection with the
control panel.
Stop
Button to reset the factory default pattern
Section menu bar
Table 3-12: Pattern parameters
Table 3-13: SMS command parameters
Parameter Software section
Action
Identifies the number of the command in the table shown.
SMS Commands
SMS text
This is the identification string to be included in the SMS command.
Shortcut
Field for the selection of one of the following shortcuts activatable from the
control panel:
•Arm/Disarm
• Stop alarms
• Clear call queue
• Delete memory
•Activate output
•Deactivate output
• Inhibit (bypass) control panel zones
• Activate (unbypass) control panel zones
•Nexus status
• Credit inquiry
• GPRS client
Shortcut parameter
Selection menu for the parameter relating to the shortcut.
Shortcut 2
Selection menu for the shortcut which is to be activated after the one selected
above.
Shortcut 2 parameter
As per “Shortcut parameter” but valid for the “Shortcut 2” command.
