20 Programming peripherals
Anti-intrusion control panels
3-4-4
Programming the patterns
Sounder/
Flasher parame-
ters
Communication loss signalling
By means of a checkbox it is possible to select exactly
when the sounder/flasher is to be activated if
communication loss with the control panel occurs:
• never
• only when wireless jamming affects
communication
• each time communication is lost
In the latter two cases it is necessary to indicate the
“Wireless supervision time”, expressed in minutes,
after which if communication is still absent the
sounder/flasher will activate.
The activation type can be defined in the same
section (selection of the sound, duration, flash
sequence, activation of the STATUS and PRG LEDs).
Configured sounder/
flashers, Wireless
sounder/flasher,
Sounder/flasher
parameters
Default
Button to reset the factory default data
Enable foam tamper signalling
If selected, it enables signalling from the anti-foam,
open panel, dislodgement and battery inefficient
sensors.
Enable anti-tamper signalling
Enable battery inefficient sig-
nalling
PRG/STATUS LED activation
In this section it is possible to indicate the source
(control panel or the sounder/flasher) of the
activation of the PRG and STATUS LEDs.
The selection of one of the two LED activation sources
excludes the other.
Sounder/
flasher LED acti-
vations
Activation cause
x
Each sounder/flasher LED (PRG or STATUS) has a
maximum of 5 checkboxes for the selection of the
control panel event that will activate the LED.
Configured sounder/
flasher, Wireless
sounder/flasher,
Sounder LED
activations
Inversion
If the “Inversion” option is not enabled, activation of
the LED will occur when the event is active. If the
“Inversion” option is enabled, LED activation will
occur when the event is not active.
Cause sounder
and flasher
shutdown
Cause
x
There are a maximum of 5 check boxes for the
selection of a control panel event that will cause
shutdown the sounder and flasher.
Configured sounder/
flasher, Wireless
sounder/flasher,
Cause of sounder
and flasher
shutdown
Inversion
If the “Inversion” option is not enabled, the sounder
and flasher will shutdown on activation of the event.
If the “Inversion” option is enabled, the sounder and
flasher will shutdown on deactivation of the event.
Monitoring
wireless
Pressing the Start button starts a monitoring phase on the variation of the signal
transmitted by the device and background noise detected over time.
Configured sounder/
flashers, Wireless
sounder/flasher,
Wireless monitoring
Table 3-11: Wireless sounder/flasher parameters
Table 3-12: Pattern parameters
Parameter Software section
Description
•Burglary
• Burglary low volume
•Fire
•Tamper
• Pre-alarm
•Automation
• Squawk
•Chime
Selection menu of the pattern to be programmed.
Sounder/flasher
pattern
Tone
This is the audible signal the sounder will emit. To be selected from the 5
available tones.
Time
This is the sounder activation time, expressed in seconds (from 1 to 127) or
minutes (from 1 to 127).
Volume
Sound level of the sounder/flasher.
Flash type
• 36 flash/min
• 46 flash/min
• 56 flash/min
•ON solid
Checkbox for the selection of the flash rate (number
of flashes per minute).
Time
This is the flasher activation time, expressed in seconds (from 1 to 127) or
minutes (from 1 to 127).
If the event that activates the flasher continuously is a zone alarm, terminal
tamper, partition alarm or partition tamper, the flasher will also be switched off
by memory reset.
Activate sounder
Enable/Disable sounder activation
Activate flasher
Enable/Disable flasher activation
