INIM Prime - Chapter 3 Programming peripherals

Programming manual
Programming peripherals 11
Chapter 3 Programming peripherals
3-1
Keypads
3-1-1
Enrolling keypads
Via softwareOnce the solution for the system to be designed has been opened, click on the System
Layout button on the menu on the left. Then click on the “Add device to BUS” button in the
section on the right.
A window will open where you can select the keypads to be configured and added to the
configuration.
In the section on the left the number increases in correspondence with the keypads button.
To remove a keypad from the structure, it is necessary to access the programming section by
clicking on the relative key on the menu on the left then, from the list shown, click on the
Delete button in correspondence with the line of the keypad in question.
Via keypad Type in Code (Installer) , PROGRAMMING Keypads, Enable/Disable
In this section you can add/remove keypads from the configuration by means of keys
and .
WIRELESS
KEYPADS
The Prime system provides guided procedures (wizards) for the enrolling of wireless keypads.
Via softwareClick on the Keypads button on the menu on the left, the section on the right will show a list
of the configured keypads.
By selecting one of these keypads, the “Keypad type” parameter will allow the association of
the “Wireless” attribute to the selected keypad. This operation visualizes:
•the Enroll button, which allows the start of the enrolling procedure.
• the “Wireless monitoring” section
Pressing the Start button initializes the monitoring process on the variation of the signal
transmitted by the device and background noise detected over time.
Via keypad Type in Code (Installer) , PROGRAMMING keypads, ChoosePeripheral "keypad", Wireless
Once the OK button is pressed, it is necessary to work through the menu options and enroll
the keypad.
3-1-2
Programming keypads
The programming of keypads as Prime system peripherals can be done either via software or
keypad.
Via softwareClick on the Keypads button on the menu on the left, to access two programming sections on
the right:
• Configured keypads, with a list of all the configured keypads. Selecting one of the
options will allow you to configure the parameters of the single keypad by clicking on the
button.
• Keypad parameters, section with parameters common to all the keypads.
Via keypad Type in Code (Installer) , PROGRAMMING Keypads, Enablements, ChoosePeripheral
This section provides a list of the available keypads.
The following symbols may appear alongside the keypad description:
• "<", indicating the keypad in use
• "*", indicating a keypad configured on the I-BUS
It is possible to select a keypad for parameter programming from this list.
ChoosePeripheral
KEYP. 001)
KEYP. 002
KEYP. 002 *
