Programming manual
Programming terminals 45
6-2-1
Outputs activatable without authentication
It is possible to program the outputs which can be viewed and activated from a keypad
without authentication (i.e. without entering a user code).
The procedure for access to these outputs depends on the type of keypad in use:
• from a keypad with keys, activate the “Output management menu” shortcut (shortcut n.
21) associated with one of the buttons , ...,
• from an Alien keypad, access the “Commands” section, then the “Home-automation”
section.
Via softwareClick on the Keypads button on the menu on the left, the section on the right will show a list
of the configured keypads.
On selection of one of the keypads, the section regarding “Details - Domotic outputs enabling”
shows a list of the outputs available on the keypad. From the list shown, you can indicate the
outputs you want to use for home-automation systems.
Outputs selected in this way can be activated by all persons with access to the keypad,
without the need of authentication via entry of a user code.
6-2-2
Output scenarios programming
A scenario is a configuration of the status of several outputs (activation type, supplied
voltage).
From the Prime/STUDIO software you can program up to 50 output scenarios, each with a
maximum of 30 outputs.
These scenarios can be used in the following ways:
• by means of the “Activate output scenario” shortcut (shortcut n.23), associated with the
system peripherals
• combined with the activation and restoral of an event
Programming is done in two phases: the first is the definition of the scenarios while the
second is the combination of event activation and restoral.
Via softwareClick on the Output scenarios button on the menu on the left, the section on the right will
show the list of the 50 available scenarios.
SCENARIO
DEFINITIONS
In this section, you can select one of the 50 available scenarios from the “Output scenarios”
field. For each of them you can program, below the checkbox in the list, each of the available
outputs.
For each of these it is necessary to indicate the output (from those configured) and the
activation type:
• 0/100 - percentage value for dimmer outputs or analogue outputs of a Flex5 expansion.
• ON - command that activates the output or, if it is a “switching” type output, changes its
operating status.
• OFF - command that deactivates the output
• Force ON - command that activates the output
• Toggle - command that changes the activation status of the output
• Open, 3/4 open,1/2 open, 1/4 open, Closed, command that changes the status of the
“roller shutter” type output
SCENARIOS ON
EVENTS
To assign one of the programmed scenarios to the each event, go to the programming section
of the event.
The “Output scenarios” section provides two programming fields for the selection of the
scenarios, one relating to activation of the event and the other to its restoral.
6-3
Double zone
The Prime system allows you to connect two different zones to a single terminal. This terminal
must be configured as “Double zone input”.
Via keypad
Type-in Code (Installer), PROGRAMMING Terminals,
select the terminal in question configured as
input (“
D
”) and then select one of the two zones.
or
Type-in Code
(Installer)
, PROGRAMMING Zones,
select the zone concerned and then select one of the
two zones
