Programming manual
Programming peripherals 27
3-8
Home-automation modules
3-8-1
Enrolling Home-automation modules
Via softwareOnce the solution for the system to be designed has been opened, click on the System
Layout button on the menu on the left. Then click on the “Add device to BUS” button in the
section on the right.
A window will open where you can select the home-automation modules to be configured and
added to the configuration..
In the section on the left the number is increased in correspondence with the button of the
home-automation modules.
To remove a home-automation module from the structure, it is necessary to access the
programming section by clicking on the corresponding button on the menu on the left then,
from the list shown, click on the Delete button in correspondence with the line of the module
to be removed.
Via keypad
Type in Code
(Installer)
, PROGRAMMING EnrolPeripherals
This section will allow you to carry out the enrolling process in two different ways:
• by manually entering the 14-digit serial code shown on the package of the home-
automation module;
• by pressing the ENROLL button on the home-automation module.
Following this operation, the home-automation module will transfer the serial code to the
control panel.
Note
All the letters entered for the code must be uppercase.
The control panel will put forward the first free address for the type of peripheral identified.
The installer can change this address as desired or confirm it by pressing the OK button.
Following this operation, it will still be possible to enable or disable the enrolled home-
automation modules via the respective menu option:
Type-in Code
(Installer)
, PROGRAMMING HomeAutom.module, Enable/disable
In this section you can add/remove the boards from the configuration by means of keys
and .
Description
String that describes the temperature sensor,
customizable by the installer
Configured
temperature
sensors, selected
sensor
TemperatureProbe,
ChoosePeripheral, "sen-
sor",
Description
Activatable out-
puts
In this section you can select the outputs that can be
activated by the thermostat function relating to the
probe being programmed.
There are 4 outputs that can be activated when the
thermostat is in “summer” mode and 4 when it is in
“winter” mode.
Not available
Temperature
hysteresis
Enter the value of the hysteresis of the sensor.
The entered value must be expressed in °C decimals
(from a minimum of 0 to a maximum of 4).
Hysteresis
Programming
the chronother-
mostat
Section relative to the programming of
chronothermostat.
You can program the thermostat and also adjust its
temperature setting and operating times.
The adjustment of the temperature (manual or
operating time mode) is allowed by indicators on level
bars.
The Read button allows you to read the thermostat
schedule and ambient temperature detected by the
provided thermometer.
The Write button allows you to set the schedule.
Not available
Table 3-19: Individual sensor parameters
