28 Programming peripherals
Anti-intrusion control panels
3-8-2
Programming of home-automation and roller
shutter modules
Programming of home-automation modules as, Prime system peripherals, can be carried out
either via software or from a keypad.
Via software By clicking on the Home-automation modules button on the menu on the left, the section
on the right will show the list of all the configured modules.
Selecting one of the options will allow you to configure the parameters of the single module by
clicking on the button.
Via keypad Type in Code (Installer) , PROGRAMMING Home-automation modules, ChoosePeripheral
This section allows you to program the various options of the selected module.
3-8-3
Parameters of Home-automation modules
The parameters of a home-automation module are different, depending on the use for which
the module has been programmed. The various possible uses are:
• Expansion module with 4 terminals
• Roller-shutter module
• “Smart” roller-shutter module
• Roller-shutter module with 1 ON/OFF button
• Roller-shutter module with 1 long press button
• Roller-shutter module with no buttons
• Venetian blind module
• Light point 1 switch and 1 relay
• Light point 1 button and 1 relay
• Light point 2 switches and 2 relays
• Light point 2 buttons and 2 relays
Table 3-20: Parameters for single boards
Parameter Software section Installer menu section
Description
This string identifies the home-automation module,
customizable by the installer.
Configured home-
automation
modules, selected
module
HomeAutom.module,
ChoosePeripheral, "mod-
ule", Description
Generic
Roller blind
Lights
Option to enable one of the operating modes of the
selected module.
Not available
Operating type
Checkbox for the selection of the operating mode
Depending on the type of operation, additional
parameters are available:
• Roll up time
• Roll down time
• Additional roll up/roll down time
• Pulse time of Venetian blind rotation
• Number of Venetian blind pulses
