Programming peripherals 19
I-BUS loss
Activation of LED input
Power failure
Open cover signalling
Foam tamper signalling
Blow-torch tamper signalling
Horn fault
Battery status
The check boxes in this section allow the association
of one or more signals to each of the sounder/flasher
events.
The available signals are aligned with the wording of
each event:
• FAULT output
•TAMPER output
•STATUS LED
•PRG LED
•Flasher
•Sounder
Audible signalling
Selection of the type of sound produced by the
magnetodynamic horn.
Maximum sound (audible signal)
time
This is the maximum time the sounder/flasher is
allowed to emit the audible signal, however, the
visual signals will continue until the device resets.
STATUS LED ON
If this option is enabled, the STATUS LED will switch
On solid.
Flashes/minute
Selects the flash rate on the flasher.
Enable flasher LED input
Option to allow blinking on the STATUS LED and PRG
LED activated by the LED input.
Monitor IBUS
If enabled, after each control panel reset, the BUS
will be monitored for one minute and its status will be
signalled on the PRG LED:
• On solid - BUS not connected
• 1 flash per second - BUS connected but sounder/
flasher not enrolled
• 2 flashes per second - BUS connected and
sounder/flasher enrolled
TAMPER and FAULT outputs
This option allows the selection of the type of contact
(normally open or closed) of the outputs during
stand-by status.
Temperature
compensation
If the internal temperature of the sounder/flasher indicated in the “Real-time” section is
incorrect, it is possible to use this section to set the real temperature value and correct
the parameter via the Compensation button.
Configured
sounder/flasher,
Hardwired
sounder/flasher,
Temperature
compensation
Sounder/
flasher LED
activations
Activation cause x
Each sounder/flasher LED (PRG or STATUS) has a
maximum of 5 checkboxes for the selection of the
control panel event that will activate the LED.
Configured
sounder/flasher,
Hardwired
sounder/flasher,
Sounder/Flasher
LED activations
Inversion
If the “Inversion” option is not enabled, activation of
the LED will occur when the event is active. If the
“Inversion” option is enabled, LED activation will
occur when the event is not active.
Cause sounder
and flasher
shutdown
Cause x
There are a maximum of 5 check boxes for the
selection of a control panel event that will cause
shutdown the sounder and flasher.
Configured
sounder/flasher,
Hardwired
sounder/flasher,
Cause sounder and
flasher shutdown
Inversion
If the “Inversion” option is not enabled, the sounder
and flasher will shutdown on activation of the event.
If the “Inversion” option is enabled, the sounder and
flasher will shutdown on deactivation of the event.
Table 3-10: Hardwired sounder/flasher parameters
Table 3-11: Wireless sounder/flasher parameters
Parameter Software section
Real-time
Pressing the Start button initiates a 4 minute countdown during which the values of
the following features of the wireless sounder/flasher will be shown:
Configured sounder/
flasher, Wireless
sounder/flasher,
Real-time
Level / foam threshold
Level / tamper threshold
From the bars it is possible to read the values (from 1
to 100) detected by the antifoam and tamper
sensors.
Using the boxes alongside, it is possible to modify the
alarm threshold. The Default button resets the
values to the factory settings.
Monitoring wireless sounder/
flasher
This section allows viewing of the sounder/flasher
status (paragraph 21-7 Monitoring sounder/flashers).
