18 Programming peripherals
Anti-intrusion control panels
If “wireless” is selected as the sounder/flasher type, the programming section will provide the
Learn button that initializes the enrolling process.
Via keypad Type in Code (Installer) , PROGRAMMING sounders/flashers, ChoosePeripheral "sounders/flash-
ers", Wireless
Once the OK button has been pressed, it is necessary to work through the menu steps to
enroll the sounder/flasher.
3-4-2
Programming sounders/flashers
The programming of a sounder/flasher as a Prime system peripheral can be carried out via
software or from a keypad.
Via software Clicking on the Sounders button on the menu on the left accesses two programming sections
on the right:
• Configured sounders/flashers, with a list of all the configured sounders/flashers.
Selecting one of the options will allow you to configure the parameters of the single
sounder/flasher by clicking on the button.
• Sounder pattern, section with the programming parameters of the tone types. 8
modifiable tones are available.
Via keypad Type in Code (Installer) , PROGRAMMING Sounders/ Flashers, ChoosePeripheral
This section provides a list of the available sounders/flashers. From this list it is possible to
select a sounder/flasher in order to program the parameters.
3-4-3
Sounder/Flasher parameters
Table 3-9: Individual sounder/flasher parameters
Parameter Software section Installer menu section
Description
Description string of the sounder/flasher
(customizable by the installer).
Configured sounder/
flasher, selected
sounder/flasher
Sounders/Flashers,
ChoosePeripheral,
"sounder/flasher"
Events
Button to open a window containing a list of the
events which activate the sounder/flasher.
Wireless
Checkbox for the assignment of the “Wireless”
attribute to the selected sounder/flasher.
Table 3-10: Hardwired sounder/flasher parameters
Parameter Software section
Real-time
Click on the Real-time option to display the following features of the sounder/flasher:
Configured
sounder/flasher,
hardwired sounder/
flasher, Real-time
Battery voltage
Voltage of the internal battery of the sounder/flasher.
Line voltage
Voltage detected on terminals 1 and 2 of the
sounder/flasher.
Temperature
Internal temperature of the sounder/flasher detected
by the thermal probe.
Foam left/right Values detected by the anti-foam sensor (left/right).
Tamper
Value detected by the open-panel tamper sensor.
Sounder/
Flasher param-
eters
Read sounder/flasher
By clicking-on the Read sounder and Write
sounder buttons it will be possible to program the
sounder/flasher parameters.
Configured
sounder/flasher,
Hardwired
sounder/flasher,
Sounder/Flasher
parameters
Write sounder/flasher
Default
Button to reset the factory default data
I-BUS loss signal delay
This is the time the sounder/flasher must wait before
signalling the loss of the I-BUS signal (expressed in
minutes).
Version
This is the firmware version of the sounder/flasher
board.
Sounder/Flasher address
Checkbox for the selection of the address of the
sounder/flasher on the BUS.
