14 Programming peripherals
Anti-intrusion control panels
TOUCH-SCREEN
KEYPADS
Exclusively via Prime/STUDIO software it is possible to program the graphic interface of the
Alien keypads and the graphic maps that can be displayed.
Once the keypad has been selected, it is necessary to select “Touch-screen keypad” as its
type. Together with the “General” section common to all types of keypads, the following
sections are shown:
• “Alien graphics”, for the graphic interface setup (backgrounds, buttons, icons)
• “Alien maps”, to configure the graphic maps accessible in the “Maps” section in the “APPs”
section (refer to Chapter 20 Graphic map configuration).
In order to configure the modified parameters on the keypad, it is necessary to have a link
between the PC to the USB port of the keypad.
The image in the lower part of the “Alien Graphic” section allows the visualization of the
graphic selected for the Alien keypad.
By double-clicking on the background or button icons it is possible to load the image from the
PC.
The image requirements depend on the device model:
• Alien/S skin:
- - the background file must be a .jpg file with a maximum size of 120 kbytes,
480x272 pixels
- - each of the 8 main buttons must be a .jpg file with a maximum size of 12 kbytes,
109x88 pixels
• Alien/G skin:
- - the background file must be a .jpg file with a maximum size of 120 kbytes,
800x480 pixels
- - each of the 8 main buttons must be a .jpg file with a maximum size of 12 kbytes,
109x88 pixels
Table 3-4: Thermostat outputs and thermal probes
Parameter Software section Installer menu section
Activable outputs
In this section it is possible to select the outputs
that can be activated by the thermostat function on
the keypad being programmed.
There are 4 outputs that can be activated when the
thermostat is in “summer” mode and 4 when it is in
“winter” mode.
Configured keypads,
selected keypad,
General, Details,
Thermostat outputs
and Thermal probes
Not available
Thermal probes
This section lists all the available thermal probes of
the system, both stand alone and integrated in the
keypads.
By means of the relative check boxes, it is possible
to select which of the probes is reachable from the
keypad being programmed.
Keypads, ChoosePe-
ripheral, "keypad",
TemperatureSens.
Table 3-5: Touch-screen keypad parameters
Parameter Software section
Communication port
This option allows selection of the connection port to the Alien keypad from those found
by the PC.
Configured keypads,
selected keypad,
Alien graphics
Refresh
Button for the connection upgrades found by the PC.
Model Checkbox for the selection of the Alien keypad.
Available Skin Selection of themes available for the Alien graphic interface.
Background Button to visualize only the Alien graphic in the background.
All Button to visualize the Alien graphic complete with buttons on the image.
Default Button to visualize the default graphic for the selected theme.
Clean Button to cancel the selected graphic.
Write skin Button to set the selected skin on the keypad.
Write icons Button to set the icons selected for the buttons on the keypad.
