34 Programming the control panel
Anti-intrusion control panels
Contaminated smoke
sensor
The smoke chamber of at least one of the Air2-
FD100 smoke detectors is contaminated by dirt or
dust.
Not available
Detector dusty
General power-supply
faults
Fault present on the power supply or one of the
power sources
Not available
Power faults
Keypad faults
Fault present on one of the keypads Not available
Keypad faults
IP connection lost
The IP connectivity test is enabled and the test has
failed
Not available
IP conn. lost
Table 4-6: Parameters for compliance
Table 4-7: EN-50131 parameters
Parameter Software section Installer menu section
50131 Grade 3 Com-
patibility
This option activates a presetting on the control
panel which adheres to grade 3 of EN50131.
• only the installer code can be used to delete
fault memories
• the readers lock for 10 minutes after 5
consecutive attempts to use a false key
• the keypads lock for 10 minutes after 5
consecutive attempts to type in a false code
(valid only when the “Lock keypad” option is
enabled)
• bypassed zones are automatically unbypassed
when the system disarms
• in the presence of ongoing faults and lost
peripherals, arming operations will require
installer code entry
Regulatory
compatibility,
Parameters 50131
Parameters
50131, Grade 3
Reader LED OFF
The readers LEDs will remain OFF when there are
no keys near the readers themselves. As soon as a
key is held near a reader and then immediately
moved away, the reader will show the status of the
LEDs for 30 seconds, after which it will switch OFF
all the LEDs again.
During this 30 second phase, the user can hold the
key in the vicinity of the reader and select the
desired shortcut indicated by LEDs.
50131ReaderLedOFF
Hide status
The status of the partitions will be hidden. If a valid
code is entered at a keypad, the real-time status
will be indicated on the keypad concerned for 30
seconds.
If partitions are armed, the real-time status of the
system will be hidden from non-authorized users.
If the partitions are disarmed, the LEDs will function
normally, the status icons will be present and the
alarm and tamper events will be visible.
50131StatHidden
Hide icons
If partitions are armed, the status icons will be
hidden from non-authorized users.
If a valid code is entered at a keypad, the status of
the icons will be shown for 30 seconds.
The keypad will show the real-time status of the
icons when all the keypad partitions are disarmed.
50131IconsHidden
Alarm delay
If an instant-zone alarm occurs on a partition while
entry time is running, the associated actions (calls,
output activation, save to log, etc.) will not be
generated until 30 seconds after the expiry of the
entry time.
If the partition (or partitions) are disarmed during
this period, the associated actions will not be
generated, however, the keypads will indicate the
violation of the instant zone.
50131AlarDelayed
Fault memory LED
If the control panel detects a fault, the yellow LED
on the keypads will go On and will remain On even
after the fault clears.
To switch the yellow LED Off, clear all activating
causes and reset the partition.
50131WarnLedMem
