User functions for the installer 85
• Zone status - allows you to view the status of all the zones. Use keys and to
scroll the list of accessible zones. The display shows the following zone parameters:
Note
It is advisable to clean the detector when the value exceeds 90%.
• Faults ongoing - allows you to view any ongoing faults.
• Panel version - allows you to view the firmware version and model of the Prime control
panel.
OUTPUTS ON/OFF
Allows manual activation/deactivation of the outputs by means of keys and .
WRITE DATE/TIME
Allows you to set the date and time of the control panel (refer to paragraph 4-2 Prime control
panel).
Via softwareThe Prime/STUDIO software program provides a section which, during a direct connection to a
Prime control panel, allows you to monitor the entire system in real time and access some of
the above-mentioned parameters.
Select the “Monitoring” option from the menu bar.
A window containing various sections will open. The sections can be selected by means of
tags, each referring to a different part of the system (refer to Chapter 21 Monitoring the
control panel).
Table 18-2: View zone status from keypad
Line Display View
1
Zone description
2
Zone status (“Standby”, “Alarm”, “Short-circuit”, “Tamper”)
and its activation status (“unbypassed” - capable of generating
alarms, or “bypassed” - incapable of generating alarms)
3
Indications that vary depending on the device type:
• wired zone; resistance value reading expressed Ohm
• wireless zone; level of wireless signal reception (from 0 to
7)
• Air2-FD100 smoke detector; level of wireless signal and
level of smoke present in the sensing chamber, expressed
in mdB/m
4
Level of contamination present in the smoke detection
chamber of Air2-FD100 smoke detector (%)
To Next Page
