Both the factory image and the application images start with firmware. First, the decision firmware loads the firmware. Then,
that firmware loads the rest of the image. These implementation details are not shown in the figure above. For more
information, refer to the Application Image Layout section.
4.4.1.3. RSU Flash Layout – Your Perspective
The sub-partition table (SPT) manages the quad SPI flash. In devices that include the HPS, the HPS can access and read the
SPT and report it to the SDM. .
The Intel Quartus Prime Programming File Generator creates the SPT when creating the initial manufacturing image. To
ensure reliable operation, the Programming File Generator creates two copies, sub-partition table and the configuration
pointer block, SPT0 and SPT1 and CPB0 and CPB1
The initial RSU image stored in flash typically contains the following partitions:
Table 39. Typical Sub-Partitions of the Initial RSU Image
Sub-partition Name Contents
BOOT_INFO Decision firmware and decision firmware data
FACTORY_IMAGE Factory Image
SPT0 Sub-partition table 0
SPT1 Sub-partition table 1
CPB0 Pointer block 0
CPB1 Pointer block 1
A1 (you enter) Application image 1
A2 (you enter) Application image 2
4. Remote System Update (RSU)
UG-20205 | 2019.10.09
Intel
®
Agilex
™
Configuration User Guide
Send Feedback
144
