Table 12. Option Bits Sector Format
Sector Offset Value
0x00–0x03
Page 0 start address
0x04–0x07
Page 0 end address
0x08–0x0B
Page 1 start address
0x0C–0x0F
Page 1 end address
0x10–0x13
Page 2 start address
0x14–0x17
Page 2 end address
0x18–0x1B
Page 3 start address
0x1C–0x1F
Page 3 end address
0x20–0x23
Page 4 start address
0x24–0x27
Page 4 end address
0x28–0x2B
Page 5 start address
0x2C–0x2F
Page 5 end address
0x30–0x33
Page 6 start address
0x34–0x37
Page 6 end address
0x38–0x3B
Page 7 start address
0x3C–0x3F
Page 7 end address
0x40–0x7F
Reserved
0x80
(6)
.pof version
0x81-0xFF
Reserved
Caution: To prevent the PFL II IP core from malfunctioning, do not overwrite any information in the option bits sector. Always store the
option bits in unused addresses in the flash memory device.
(6)
The .pof version occupies only one byte in the option bits sector.
