3.1.10.1.6. Verifying the Option Bit Start and End Addresses
You can decode the start and end address that you specified for each of the SOF page when converting a .sof to .pof file
from the 32-bit value of the sector offset address. If you encounter a configuration error you can verify that the generated
bitstream addresses match the addresses you specified in the Intel Quartus Prime Software.
The following table shows the bit fields of the start address.
Table 13. Start Address Bit Content
Bit Width Description
31:11 21 Addressable start address
10:1 10 Reserved bits
0 1 Page valid bit
• 0=Valid
• 1=Error
Table 14. End Address Bit Content
Bit Width Description
31:0 32 Addressable end address
To restore the addresses:
• Start address—append 13'b0000000000000 to the addressable start address
• End address—append 2'b11 to the addressable end address
For a .pof that has two page addresses with the values shown in the following table.
Sector Offset
Value
0x00 – 0x03 0x00004000
0x04 – 0x07 0x00196E30
0x08 – 0x0B 0x001C0000
3. Intel Agilex Configuration Schemes
UG-20205 | 2019.10.09
Intel
®
Agilex
™
Configuration User Guide
Send Feedback
68
