Intel Arria 10 FPGA User Manual

Board Reference Schematic Signal
Name
FPGA Pin Number I/O Standard Description
D2 FM_A5 AM13 1.8 V Address bus
A2 FM_A6 AE12 1.8 V Address bus
C2 FM_A7 AN15 1.8 V Address bus
A3 FM_A8 AL10 1.8 V Address bus
B3 FM_A9 AR10 1.8 V Address bus
C3 FM_A10 AP11 1.8 V Address bus
D3 FM_A11 AL13 1.8 V Address bus
C4 FM_A12 AH11 1.8 V Address bus
A5 FM_A13 AN14 1.8 V Address bus
B5 FM_A14 AG11 1.8 V Address bus
C5 FM_A15 AH10 1.8 V Address bus
D7 FM_A16 AF14 1.8 V Address bus
D8 FM_A17 AF15 1.8 V Address bus
A7 FM_A18 AH14 1.8 V Address bus
B7 FM_A19 AJ12 1.8 V Address bus
C7 FM_A20 AJ14 1.8 V Address bus
C8 FM_A21 AH13 1.8 V Address bus
A8 FM_A22 AG12 1.8 V Address bus
G1 FM_A23 AJ13 1.8 V Address bus
H8 FM_A24 AF12 1.8 V Address bus
B6 FM_A25 AK14 1.8 V Address bus
B8 FM_A26 AK11 1.8 V Address bus
F2 FM_D16 AT25 1.8 V Data bus
E2 FM_D17 BA19 1.8 V Data bus
G3 FM_D18 BA20 1.8 V Data bus
E4 FM_D19 AP24 1.8 V Data bus
E5 FM_D20 AP23 1.8 V Data bus
G5 FM_D21 BA18 1.8 V Data bus
G6 FM_D22 AT24 1.8 V Data bus
H7 FM_D23 BD19 1.8 V Data bus
E1 FM_D24 AU23 1.8 V Data bus
E3 FM_D25 AR24 1.8 V Data bus
F3 FM_D26 AT23 1.8 V Data bus
F4 FM_D27 AR25 1.8 V Data bus
F5 FM_D28 AP22 1.8 V Data bus
continued...
6. Board Components
683526 | 2023.07.12
Send Feedback
Intel
®
Arria
®
10 FPGA Development Kit User Guide
103
