6.5.4. Character LCD
The Arria 10 GX FPGA development board includes a single 10-pin 0.1" pitch single-
row header that interfaces to a 16 character × 2 line Lumex LCD display. The LCD has
a 10-pin receptacle that mounts directly to the board's 10-pin header, so it can be
easily removed for access to components under the display. You can also use the
header for debugging or other purposes.
Table 21. Character LCD Schematic Signal Names and Functions
Board
Reference
Schematic
Signal Name
FPGA Pin
Number
I/O Standard Description
5 SPI_SS_DISP /
DISP_SPISS
BA35 1.8 V SPI slave select (only used in SPI mode)
7 I2C_SCL_DISP
/
DISP_I2C_SCL
AW33 1.8 V I
2
C LCD serial clock
8 I2C_SDA_DISP
/
DISP_I2C_SDA
AY34 1.8 V I
2
C LCD serial data
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
70
