Table 20. User-Defined LEDs Schematic Signal Names and Functions
Board Reference Schematic Signal Name FPGA Pin Number I/O Standard
D10 USER_LED_G0 L28 1.8 V
D9 USER_LED_G1 K26 1.8 V
D8 USER_LED_G2 K25 1.8 V
D7 USER_LED_G3 L25 1.8 V
D6 USER_LED_G4 J24 1.8 V
D5 USER_LED_G5 A19 1.8 V
D4 USER_LED_G6 C18 1.8 V
D3 USER_LED_G7 D18 1.8 V
D10 USER_LED_R0 L27 1.8 V
D9 USER_LED_R1 J26 1.8 V
D8 USER_LED_R2 K24 1.8 V
D7 USER_LED_R3 L23 1.8 V
D6 USER_LED_R4 B20 1.8 V
D5 USER_LED_R5 C19 1.8 V
D4 USER_LED_R6 D19 1.8 V
D3 USER_LED_R7 M23 1.8 V
