6.9. Board Power Supply
This section describes the Arria 10 GX FPGA development board’s power supply. A
laptop style DC power supply is provided with the development kit. Use only the
supplied power supply. The power supply has an auto sensing input voltage range of
100 ~ 240 VAC and will output 12 VDC power at 16 A to the development board. The
12 VDC input power is then stepped down to various power rails used by the board
components.
An on-board multi-channel analog-to-digital converter (ADC) measures both the
voltage and current for several specific board rails. The power utilization is displayed
on a graphical user interface (GUI) that can graph power consumption versus time.
