6.7.5. QSFP
The Arria 10 GX FPGA development board includes a QSFP module.
Table 35. QSFP Pin Assignments, Schematic Signal Names, and Functions
Board Reference Schematic Signal
Name
FPGA Pin
Number
I/O Standard Description
28 QSFP_3P3V_INTERRUPT
N
AL34 1.8 V QSFP interrupt
31 QSFP_3P3V_LP_MODE AK34 1.8 V QSFP low power mode
27 QSFP_3P3V_MOD_PRSN AU36 1.8 V Module present
8 QSFP_3P3V_MOD_SELN AU35 1.8 V Module select
9 QSFP_3P3V_RSTN AV35 1.8 V Module reset
11 QSFP_3P3V_SCL AV34 1.8 V QSFP serial 2-wire clock
12 QSFP_3P3V_SDA AU31 1.8 V QSFP serial 2-wire data
18 QSFP_RX_N0 R41 High Speed
Differential I/O
QSFP transmitter data
21 QSFP_RX_N1 P39 High Speed
Differential I/O
QSFP transmitter data
15 QSFP_RX_N2 M39 High Speed
Differential I/O
QSFP transmitter data
24 QSFP_RX_N3 L41 High Speed
Differential I/O
QSFP transmitter data
17 QSFP_RX_P0 R42 High Speed
Differential I/O
QSFP transmitter data
22 QSFP_RX_P1 P40 High Speed
Differential I/O
QSFP transmitter data
14 QSFP_RX_P2 M40 High Speed
Differential I/O
QSFP transmitter data
25 QSFP_RX_P3 L42 High Speed
Differential I/O
QSFP transmitter data
37 QSFP_TX_N0 K43 High Speed
Differential I/O
QSFP transmitter data
2 QSFP_TX_N1 J41 High Speed
Differential I/O
QSFP transmitter data
34 QSFP_TX_N2 G41 High Speed
Differential I/O
QSFP transmitter data
5 QSFP_TX_N3 F43 High Speed
Differential I/O
QSFP transmitter data
36 QSFP_TX_P0 K44 High Speed
Differential I/O
QSFP transmitter data
3 QSFP_TX_P1 J42 High Speed
Differential I/O
QSFP transmitter data
33 QSFP_TX_P2 G42 High Speed
Differential I/O
QSFP transmitter data
6 QSFP_TX_P3 F44 High Speed
Differential I/O
QSFP transmitter data
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
98
