K J H G F E D C B A
35 FMCB_DP_C2M_N14 GND FMCB_LA_TX_N15 GND NC GND FMCB_GA1 12V GND FMCB_DP_C2M_N4
36 GND NC GND FMCB_LA_RX_P14 GND NC 3.3V GND FMCB_DP_C2M_P6 GND
37 FMCB_DP_C2M_P15 GND FMCB_LA_TX_P16 FMCB_LA_RX_N14 NC NC GND 12V FMCB_DP_C2M_N6 GND
38 FMCB_DP_C2M_N15 GND FMCB_LA_TX_N16 GND NC GND 3.3V GND GND FMCB_DP_C2M_P5
39 GND NC GND A10_VCCIO_FMCB GND A10_VCCIO_FMCB GND 3.3V GND FMCB_DP_C2M_N5
40 NC GND A10_VCCIO_FMCB GND A10_VCCIO_FMCB GND 3.3V GND NC GND
LPC Connector LPC Connector HPC Connector HPC Connector
6.10.1.5.1. High Pin Count (HBC)
The High Pin Count FMC connections are assigned to columns G and H in both the
FMCA (J1) and FMCB (J2) connectors as shown. The HPC signaling follows the Vita57.1
standard.
6.10.1.5.2. Low Pin Count (LPC)
The Low Pin Count FMC connections are assigned to columns C and D in both the
FMCA (J1) and FMCB (J2) connectors as shown. The LPC signaling follows the Vita57.1
standard.
6. Board Components
683526 | 2023.07.12
