The BTS communicates over the JTAG bus to a test design running in the FPGA. The
Board Test System and Power Monitor share the JTAG bus with other applications like
the Nios II debugger and the SignalTap
®
II Embedded Logic Analyzer. Because the
BTS is designed based on the Quartus Programmer and System Console, be sure to
close other applications before you use the BTS application.
