Intel Arria 10 FPGA User Manual

If you do not know, or are unsure of the version, enter the board serial number in the
box on the right and the software will pick the right version based on the table below.
The numbers here are the last 3-4 digits of the serial number which can be found on
the bottom of your board.
Figure 14. Board Serial Number Sticker
Table 12. Serial Number to Arria 10 Silicon Revision
Serial Number Arria 10 Silicon Revision
10APCIe000[< 0332] ES2
10APCIe000[0332 – 0383] PRD-1
10APCIe000[0500 – 0999] ES3
10APCIe000[1000+] PRD
4. Board Test System
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
24
