Control Description
• Detected errors—Displays the number of data errors detected in the
hardware.
• Inserted errors—Displays the number of errors inserted into the
transaction stream.
• Insert Error—Inserts a one-word error into the transaction stream
each time you click the button. Insert Error is only enabled during
transaction performance analysis.
• Clear—Resets the Detected errors and Inserted errors counters to
zeroes.
Number of Addresses to Write and Read Determines the number of addresses to use in each iteration of reads and
writes.
