Board Reference Schematic Signal Name I/O Standard
D11 FMCA_PRSNTn 1.8 V
D18 FMCB_TX_LED 1.8 V
D20 FMCB_RX_LED 1.8 V
D21 FMCB_PRSNTn 1.8 V
D34 PCIE_LED_X1 1.8 V
D35 PCIE_LED_X4 1.8 V
D36 PCIE_LED_X8 1.8 V
D37 PCIE_LED_G2 1.8 V
D38 PCIE_LED_G3 1.8 V
