Board Reference

(U15)

Schematic Signal

Name

FPGA Pin Number I/O Standard Description

77 ENET_RX_P AV24 SGMII receive channel

81 ENET_TX_N BD23 SGMII transmit channel

82 ENET_TX_P BC23 SGMII transmit channel

55 ENET_XTAL_25MH

— 2.5 V 25-MHz RGMII transmit clock

31 MDI_N0 — Media dependent interface

34 MDI_N1 —

41 MDI_N2 —

43 MDI_N3 —

29 MDI_P0 —

33 MDI_P1 —

39 MDI_P2 —

42 MDI_P3 —

6. Board Components

683526 | 2023.07.12

Intel

Arria

10 FPGA Development Kit User Guide
