Intel Arria 10 FPGA User Manual

Board Reference Schematic Signal Name FPGA Pin Number I/O Standard
C2 MEM_DQA10 G26 1.5 V
C3 MEM_DQA11 H26 1.5 V
E3 MEM_DQA12 G28 1.5 V
D4 MEM_DQA13 F27 1.5 V
D1 MEM_DQA14 K27 1.5 V
D2 MEM_DQA15 F28 1.5 V
A12 MEM_DQA16 D31 1.5 V
B12 MEM_DQA17 E31 1.5 V
B13 MEM_DQA18 B31 1.5 V
B14 MEM_DQA19 C31 1.5 V
C15 MEM_DQA20 A30 1.5 V
A16 MEM_DQA21 E30 1.5 V
B16 MEM_DQA22 B30 1.5 V
A18 MEM_DQA23 D29 1.5 V
C16 MEM_DQA24 K30 1.5 V
D16 MEM_DQA25 H30 1.5 V
E16 MEM_DQA26 G30 1.5 V
F16 MEM_DQA27 K31 1.5 V
D17 MEM_DQA28 H29 1.5 V
C18 MEM_DQA29 K29 1.5 V
D18 MEM_DQA30 J29 1.5 V
E18 MEM_DQA31 F29 1.5 V
E2 MEM_DQA32 J28 1.5 V
G16 MEM_DQA33 G31 1.5 V
H16 MEM_DQB0 AC31 1.5 V
J16 MEM_DQB1 AB31 1.5 V
K16 MEM_DQB2 W31 1.5 V
L16 MEM_DQB3 Y31 1.5 V
H17 MEM_DQB4 AD31 1.5 V
K17 MEM_DQB5 AD32 1.5 V
K18 MEM_DQB6 AD33 1.5 V
L18 MEM_DQB7 AA30 1.5 V
M17 MEM_DQB8 AE31 1.5 V
N18 MEM_DQB9 AE32 1.5 V
P17 MEM_DQB10 AE30 1.5 V
P18 MEM_DQB11 AF30 1.5 V
continued...
6. Board Components
683526 | 2023.07.12
Send Feedback
Intel
®
Arria
®
10 FPGA Development Kit User Guide
83
