Board Reference Schematic Signal Name FPGA Pin Number I/O Standard
H18 MEM_DQSB_P0 Y32 1.5 V
U18 MEM_DQSB_P1 AJ32 1.5 V
V16 MEM_DQSB_P2 AA34 1.5 V
V8 MEM_DQSB_P3 AF33 1.5 V
A11 MEM_QKA_P0 C28 1.5 V
B18 MEM_QKA_P1 E29 1.5 V
M18 MEM_QKB_P0 Y30 1.5 V
V13 MEM_QKB_P1 V33 1.5 V
H14 MEM_VREF AB30 —
J13 MEM_VREF K32 —
K14 MEM_VREF R32 —
