Intermec EasyCoder PX4i User Manual

Chapter 10 — Troubleshooting
112 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
Overall Dark Printout
Possible Cause Remedy Reference
Wrong media grade Change parameter “Setup Parameters” on
page 62
Contrast value too
high
Change parameter “Setup Parameters” on
page 62
Printhead pressure
too high
Adjust “Printhead Pressure” on
page 131
Wrong printhead
voltage
Replace CPU board  Call Service
Excessive Bleeding
Possible Cause Remedy Reference
Wrong media grade Change parameter “Setup Parameters” on
page 62
Contrast value too
high
Change parameter “Setup Parameters” on
page 62
Printhead pressure too
high
Adjust pressure “Printhead Pressure” on
page 131
Faulty energy control Replace CPU board  Call Service
Dark Lines Along Media Path
Possible Cause Remedy Reference
Foreign objects on
printhead
Clean printhead “Printhead
Cleaning” on
page 116
White Vertical Lines
Possible Cause Remedy Reference
Printhead dirty Clean printhead “Printhead Cleaning”
on page 116
Missing printhead Replace printhead “Replacing the
Printhead” on page 123

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
