Intermec EasyCoder PX4i User Manual

Chapter 10 — Troubleshooting
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 113
Large Part Of Dot Line Missing
Possible Cause Remedy Reference
Failing printhead Replace printhead “Replacing the
Printhead” on
page 123
Failing strobe signal Check CPU-board  Call Service
Printout Missing Along Inner Edge
Possible Cause Remedy Reference
Bad media alignment Adjust “Loading Media” on
page 23
Using small core with
supply post in upper
position.
Move post to lower
position
“Installation” on
page 5
X-start parameter value
too low
Increase value “Setup Parameters”
on page 62
Transfer Ribbon Breaks
Possible Cause Remedy Reference
Ribbon not fitted
correctly
Reload ribbon correctly “Loading Ribbon” on
page 52
Wrong media grade Change parameter, then
clean printhead
“Setup Parameters”
on page 62
Bad energy control Adjust
 Call Service
Transfer Ribbon Wrinkles
Possible Cause Remedy Reference
Faulty ribbon break shaft
adjustment
Adjust “Narrow Media” on
page 130
Incorrect edge guide
adjustment
Adjust “Loading Media” on
page 23
Printhead pressure too
strong
Adjust pressure “Printhead Pressure” on
page 131

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
