Interroll RM 8310 - 24-V Deep Freeze Straight Roller Conveyor (RM 8310 DF); Components; Property

Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Product identification
14 Version 1.5 (07/2020) en
Translation of original operating instructions
24-V Deep Freeze Straight Roller Conveyor (RM 8310 DF)
Components
2 3 4 5 6 7 8 10 11 12 141391
24-V Straight Roller Conveyor RM 8310
1 Side frame 8 Roller clip
2 RollerDrive (drive roller) 9 Finger guard
3 Roller 10 Side frame cover
4 Drive belt (roller-to-roller) 11 Photo cell
5 Control system 12 End cap (of side frame)
6 Side guide bracket 13 Universal support
7 Side guide profile 14 Reflector
Property
The 24-V roller conveyor enables zero pressure accumulation transport of goods with the help
of a control system. Each zone is powered by a RollerDrive that is connected to a fixed number
of idlers via PolyVee belts.
RM8310DF can be used in the deep freeze area up to −28°C.
