Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Product identification
24 Version 1.5 (07/2020) en
Translation of original operating instructions
24-V Deep Freeze Merge Roller Conveyor (RM 8330 DF)
Components
1 3 4 6
7
8
10
11
12
52
9
24-V merge roller conveyor RM 8330
1 End cap (of side frame) 7 Drive belt (roller-to-roller)
2 End cap (of side guide) 8 Roller clip
3 RollerDrive (drive roller) 9 Finger guard
4 Side guide profile 10 Roller
5 Universal support 11 Side frame cover
6 Side guide bracket 12 Control system
Property
The merge merges two conveyor lines by placing products in the gaps in the flow of material.
Alternatively, the merge diverts products from a straight conveyor, e.g., by using an HPD
(High Performance Divert).
RM8330DF can be used in the deep freeze area up to −28°C.
