Interroll RM 8310 - Replacing the Carrying Idler in the Curve

Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Maintenance and repair
58 Version 1.5 (07/2020) en
Translation of original operating instructions
Replacing the carrying idler in the curve
1 2
3
3 4
2
1 Roller 3 Fastening screw for roller
2 Side frame cover 4 Drive belt
CAUTION
Risk of crushing from rotating parts
4 Before any assembly and maintenance work, the respective devices must be
decommissioned and disconnected from the voltage supply.
4 Secure the respective devices against accidental activation.
4 When integrating the module into a complete system, consider possible danger spots,
particularly infeed locations and interfaces.
