Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Maintenance and repair
66 Version 1.5 (07/2020) en
Translation of original operating instructions
Replacing the drive belt
1 Roller 4 Drive belt
2 Serrated flange bolts 5 Side frame
3 Side frame cover
CAUTION
Risk of crushing and electric shock
Installation and maintenance tasks on a conveyor system during its operation can lead to
crushing and electric shock.
4 De-energize the module and ensure that it cannot be started accidentally.
