Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Product identification
Version 1.5 (07/2020) en
Translation of original operating instructions
17
24-V/48-V Curve Roller Conveyor (RM 8320)
Components
9
21 3 4 56 7
64
10
8
11
24-V/48-V curve roller conveyor RM 8320
1 RollerDrive (drive roller) 7 Side frame cover
2 Roller 8 Mounting bracket
3 Side guide profile 9 End cap (of side frame)
4 Universal support 10 Control system
5 Drive belt (roller-to-roller) 11 Side frame
6 Side guide bracket
Property
The DC roller conveyor curves change the direction of transport of conveying goods. The
tapered rollers retain the alignment of the conveying goods between the side frames. A control
system enables zero pressure accumulation transport. Each zone is driven by a DC RollerDrive
that is connected to a fixed number of idlers via round belts.
RM8320 can also be used in the chill area.
