Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Product identification
Version 1.5 (07/2020) en
Translation of original operating instructions
25
Technical data
Merge RM 8330 DF
Max. load capacity per zone 25kg
Ambient temperature in operation –28 to 0 °C
Ambient temperature during transport
and storage
–30 to +75 °C
Roller type Interroll Series 3500
Roller diameter 50mm
Roller material Steel 1.5mm, zinc-plated
Roller material option Stainless steel rollers
Roller bearing version Precision ball bearing 6002 2RZ, oiled
Motor type Interroll RollerDrive EC310 DF
Rated voltage 24V
Torque transmission Roller-to-roller
Drive medium PolyVee belts
Control variants MultiControl
Incline/decline Not suitable
Side profile 115x35mm, without side guide
Rated width 420 to 620mm
Roller pitch (P) 60mm
Side guide Without, fixed or flexible, left or right
Merging angle 30°
45°
Noise level Leq ≤ 70 dB (A)
Roller merge dimensions
The angle and lane width of a merge or diverter module define the dimensions of the module.
The following table shows the standard dimensions of the merge/diverter modules (merges).
Between frames BF
in mm
Module length ML
in mm
Module length ML
in mm
For angle α = 45° and
roller pitch P = 60 mm
For angle α = 30° and
roller pitch P = 60 mm
420 510 810
620 690 1140
840 930 1540
