Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Maintenance and repair
78 Version 1.5 (07/2020) en
Translation of original operating instructions
Replacing the end cap
1 End cap 2 Side frame cover
4 Remove end caps (1) from the side frame using a tool (e.g., screwdriver).
4 Push the new end caps into the C-profile of the side frame.
