Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
32 Version 1.5 (07/2020) en
Translation of original operating instructions
Installation
WARNING
Risk of injury due to improper assembly
4 Mechanical assembly tasks should be performed only by service personnel. Observe the
safety information.
4 Electrical assembly tasks should be performed only by authorized electricians. Observe the
safety information.
4 Carefully install all terminals and connections, such as cables, hoses and pipework,
and check for correct fit.
The module is delivered to the installation site as a pre-assembled unit and must be set up,
connected and integrated into a system on site.
In principle, photo cell and reflector, as well as the control system, are already completely
assembled and connected. The side guides (universal support, side guide bracket and side guide
profiles) are delivered either assembled or unassembled, according to customer specifications.
The following steps are required for installation and integration into a complete system:
Install supports, see "Installing supports", page34
Connect the modules, see "Connecting the modules", page35
If one of the following components is not yet installed, the corresponding steps must be
performed:
Install photo cell and reflector,
see "Installing the photo cell and reflector", page37
Install side guide profiles,
see "Installing the side guide profiles", page39
Install side frame cover and end caps,
see "Installing side frame cover and end caps", page45
Install finger guard (PolyVee),
see "Installing the finger guard (PolyVee guard)", page46
