Interroll RM 8310 - Installing Side Frame Cover and End Caps

Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Installation
Version 1.5 (07/2020) en
Translation of original operating instructions
45
Installing side frame cover and end caps
2
1
21
1 End caps 2 Side frame cover
4 Snap side frame cover (2) into the C-profile of the side frame.
4 Push end caps (1) into the C-profile of the side frame.
