Interroll RM 8310 - Electrical Installation

Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Installation
50 Version 1.5 (07/2020) en
Translation of original operating instructions
Electrical installation
The power supply of the module is provided via MultiControl.
DANGER
Danger to life – electrocution
An improper electrical installation threatens the lives of the installer and the users of the
electrical system. It could result in personal liability in case of personal injuries or property
damage, e.g. through a fire.
4 Check cables and components for damage before installation.
4 The connection values of the module are located on the motor type plate.
4 Observe the information about connecting the RollerDrive in the "Interroll MultiControl"
operating instructions.
NOTICE
Destruction of the RollerDrive in case of incorrect connection values
Destruction of the motor electronics
4 Do not operate the RollerDrive EC5000 24VDC with 48VDC.
4 Observe the colored ring on the motor connector.
Colored rings on the connectors of the RollerDrive EC5000:
Colored ring RollerDrive EC5000 version
White Analog interface, 24 V DC
Gray Bus interface, 24 V DC
Black Analog interface, 48 V DC
Yellow Bus interface, 48 V DC
NOTICE
The RollerDrive EC5000 BI is not hot-plug-capable
Destruction of the RollerDrive EC5000 with bus interface when connecting/disconnecting while it
is supplied with voltage.
4 Switch off the voltage supply before connecting/disconnecting the RollerDrive EC5000 BI!
