Interroll RM 8310 - Replacing the Flexible Universal Support

Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Maintenance and repair
Version 1.5 (07/2020) en
Translation of original operating instructions
75
Replacing the flexible universal support
7
6
5
23
4
1
4
1
1 Side guide profile 5 Mounting bracket
2 Side frame cover 6 Hexagon nuts
3 Clamping plate 7 Universal support cover
4 Side guide bracket
