CAUTION
Risk of crushing and electric shock
Installation and maintenance tasks on a conveyor system during its operation can lead to
crushing and electric shock.
4 De-energize the module and ensure that it cannot be started accidentally.
Requirement:
R The module is shut down.
4 Open the cover of the side guide bracket (7) with a tool (e.g. screwdriver).
4 Loosen the hexagon nut (6).
4 Move the hammer head bolt (3) inside the side guide bracket to the horizontal position by
turning it and pull it out of the side profile.
4 Pull the side guide bracket (2) off the mounting bracket (5) of the universal support (4).
4 Loosen the hexagon nut on the new side guide bracket, but do not remove it. Create
sufficient clearance so that the hammer head bolt can later be inserted into the side profile
and the clamp can be pushed onto the mounting bracket.
4 Push the new side guide bracket onto the mounting bracket of the universal support.
If needed, break out the upper hole cover.
4 Insert the hammer head bolt into the side profile by slightly turning it.
4 Tighten the hexagon nut.
ð The hammer head bolt is fixed. The side guide bracket sits firmly on the universal support.
4 Close the top cover and snap it in.
