Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Installation
36 Version 1.5 (07/2020) en
Translation of original operating instructions
The roller top edge is decisive for the alignment of the modules. Suitable tools for the alignment
are spirit level or rotation laser.
4 Position the modules to be connected so that the side frames (4) are aligned.
4 On the insides of the modules to be connected, place one profile connector (3) each at the
side frames. The noses of the profile connectors must catch in the elongated holes of the side
frames.
4 Fasten profile connectors to the perforated profiles of the side frames using screws (2). Use
two screws for each module. Place a spring washer (5) under screws that are used in
elongated holes.
4 Fasten the module torsion-free, e.g., by anchoring it to the floor or to adjacent components.
