Installation
38 Version 1.5 (07/2020) en
Translation of original operating instructions
Requirement:
R The module is out of operation.
4 Separate strap (2) as well as photo cell (4) and/or reflector (1) from the sprue clip.
4 Professionally dispose of the sprue.
4 Place the photo cell on the module at the desired location. Reverse the strap when installing
it on a side guide.
4 Place the strap (2) on the mounting cam (3) at the underside of the photo cell and snap it
into place.
A setscrew in the foot of the photo cell holder is intended for the fine adjustment of the photo
cell. Turning the setscrew in slightly raises the photo cell until it "sees" the reflector.
4 Install the reflector opposite the photo cell.
4 Analogous to the photo cell holder, place the strap (2) onto the mounting cams at the
underside of the reflector and snap it into place.
4 After installing the photo cell and reflector: Connect the photo cell to the control system of
the module with a cable.
4 Check whether both LEDs are lit.
4 If the yellow LED flashes, position reflector and photo cell to each other.
LED green LED yellow Meaning
On Off Photo cell is operational.
No signal from reflector.
On On Photo cell is correctly adjusted.
Light beam is well reflected.
On Flashing Photo cell is operational.
Weak signal.
Reflector is dirty, damaged or not correctly adjusted.
