For pitches equal to 60mm, install the finger guard in two steps:
4 First, clip the top part (2) into a pocket hole.
4 Next, push the bottom part (3) onto the top part. This requires access to the conveyor belt
from below.
For pitches greater than 60mm, it is possible to install the pre-assembled top and bottom part
as a complete unit. In this case, two complete finger guards are required.
4 Install each of the complete finger guards directly adjacent to the roller.
For pitches greater than 90mm, a gap is created between two finger guards.
CAUTION
Possible crushing by reaching into the gap between roller and belt/finger guard.
4 Do not reach into the gap between rollers and belt or finger guard.
4 When manually placing or removing material during running operation, always reach to the
middle of the conveyor belt from the top.
