Interroll 24-V/48-V Roller Conveyor
RM 8310/8310 DF, RM 8320/8320 DF, RM 8330/8330 DF
Spare and wear parts
86 Version 1.5 (07/2020) en
Translation of original operating instructions
Type: 8310
Item No. Designation Material number S/W/T
7 Side guide profile, polymer/aluminum See project data S
8 Side guide bracket 63010248 S
9 Universal support See project data S
10 Side frame cover 1015143 S
11 Side frame end cap 64000900 S
12 Side guide end cap 63010039 S
13.1 Roller clip 64000908 S
13.2 RollerDrive tab 63101442 S
13.3 RollerDrive fastener from top 63115532 S
14 Finger guard 64100973 S
16 MultiControl cover
(Only if MultiControl is used as the
control system)
64100350 S
Type: 8310 DF
Item No. Designation Material number S/W/T
1 RollerDrive (drive roller)
EC 310 DF (with oiled ball bearing)
See project data S
2 Roller, ø50
DF (with oiled ball bearing)
See project data S
3 PolyVee belt See project data W
4 Control system See project data S
