Goodrive200 inverters Function codes
102
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
which is relative to the sudden jumping
frequency.
The raising time of the traverse frequency: The
time from the lowest point to the highest one.
The declining time of the traverse frequency: The
time from the highest point to the lowest one.
The setting range of P08.15: 0.0~100.0%
(relative to the set frequency)
The setting range of P08.16: 0.0~50.0%
(relative to the traverse range)
The setting range of P08.17: 0.1~3600.0s
The setting range of P08.18: 0.1~3600.0s
P08.19
Setting
length
The function codes of setting length, actual
length and unit pulse are mainly used to control
the fixed length.
The length is counted by the pulse signal of HDI
terminals input and the HDI terminals are needed
to set as the length counting input.
Actual length＝the length counting input pulse
/unit pulse
When the actual length P08.20 exceeds the
setting length P08.19, the multi-function digital
output terminals will output ON.
Setting range of P08.19: 0~65535m
Setting range of P08.20:0~65535m
Setting range of P08.21:1~10000
Setting range of P08.22:0.01~100.00cm
Setting range of P08.23:0.001~10.000
Setting range of P08.24:0.001~1.000
0m ○
P08.20
Actual
length
0m ●
P08.21
Pulse per
rotation
1 ○
P08.22
Alxe
perimeter
10.00
cm
○
P08.23
Length
ratio
1.000
○
P08.24
Length
correcting
coefficient
1.000
○
P08.25
Setting
counting
The counter works by the input pulse signals of
the HDI terminals.
0 ○
