Goodrive200 inverters Keypad operation procedure
40
5.3 Keypad displaying
The keypad displaying state of Goodrive200 series inverters is divided into stopping state
parameter, running state parameter, function code parameter editing state and fault alarm
state and so on.
5.3.1 Displayed state of stopping parameter
When the inverter is in the stopping state, the keypad will display stopping parameters which
is shown in figure 5-2.
In the stopping state, various kinds of parameters can be displayed. Select the parameters
to be displayed or not by P07.07. See the instructions of P07.07 for the detailed definition of
each bit.
In the stopping state, there are 13 stopping parameters can be selected to be displayed or
not. They are: setting frequency, bus voltage, input terminals state, output terminals state,
PID reference, PID feedback, AI1, AI2, AI3, HDI, PLC and the current step of multi-step
speeds, pulse counting value, length value. P07.07 can select the parameter to be displayed
or not by bit and/SHIFT can shift the parameters form left to right, QUICK/JOG(P07.02=2)
can shift the parameters form right to left.
5.3.2 Displayed state of running parameters
After the inverter receives valid running commands, the inverter will enter into the running
state and the keypad will display the running parameters. RUN/TUNE LED on the keypad is
on, while the FWD/REV is determined by the current running direction which is shown as
figure 5-2.
In the running state, there are 23 parameters can be selected to be displayed or not. They
are: running frequency, set frequency, bus voltage, output voltage, output torque, PID
reference, PID feedback, input terminals state, output terminals state, torque set value,
length value, PLC and the current step of multi-step speeds, pulse counting value, AI1, AI2,
AI3, HDI, percentage of motor overload, percentage of inverter overload, ramp reference
value, linear speed, AC input current. P07.05 and P07.06 can select the parameter to be
displayed or not by bit and /SHIFT can shift the parameters form left to right,
QUICK/JOG(P07.02=2) can shift the parameters from right to left.
5.3.3 Displayed state of fault
If the inverter detects the fault signal, it will enter into the fault pre-alarm displaying state. The
keypad will display the fault code by flicking. The TRIP LED on the keypad is on, and the
fault reset can be operated by theSTOP/RST on the keypad, control terminals or
