Goodrive200 inverters Product overview
13
Note:
1. The inverter above 37kW (including 37kW) supports external DC reactor which is an
optional part. Before connecting, it is necessary to remove the copper row between P1 and
（+）.
2. The inverter below 30kW (including 30kW) supports external braking resistor; the inverter
above 37kW (including 37kW) supports external braking units. Both the braking unit and the
braking resistor are optional parts.
3.3 Product specification
Function Specification
Input
Input voltage (V)
AC 3PH 220V(-15%)~240V(+10%)
AC 3PH 380V(-15%)~440V(+10%)
AC 3PH 520V(-15%)~690V(+10%)
Input current (A) Refer to the rated value
Input frequency (Hz)
50Hz or 60Hz
Allowed range: 47~63Hz
Output
0~Input voltage
Output current (A)
Refer to the rated value
Output power (kW)
Refer to the rated value
Output frequency (Hz)
0~400Hz
Technical
control
feature
Control mode SVPWM, SVC
Motor type Asynchronous motor
Speed ratio Asynchronous motor 1:200 (SVC)
Speed control
accuracy
±0.2% (sensorless vector control)
Speed fluctuation
± 0.3%(sensorless vector control)
Torque response <20ms(sensorless vector control)
Torque control
accuracy
10%(sensorless vector control)
Starting torque Asynchronous motor: 0.25Hz/150% (SVC)
Overload capability
G type:
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
